| Specification |
DT-MINI-2 |
DT-MINI-2-GS |
| Dimensions: |
153.4 mm x 104.9 mm x 40.9 mm |
140 mm x 50 mm x 125 mm |
| Weight: |
330 g |
475 g |
| Wavelength range: |
200-410 nm (deuterium); 360-2000 nm
(tungsten halogen) |
200-410 nm (deuterium); 360-2000 nm
(tungsten halogen) |
| Power consumption: |
350 mA @ 12 VDC |
350 mA @ 12 VDC |
| Output: |
3.8 watts (deuterium); 1.2 watts (tungsten
halogen) |
3.8 watts (deuterium); 1.2 watts (tungsten
halogen) |
| Stability: |
0.3% peak-to-peak (over 4 hours) after
30-minute warm-up |
0.3% peak-to-peak (over 4 hours) after
30-minute warm-up |
| Time to stable output: |
10 minutes (deuterium); 1 minute (tungsten
halogen) |
10 minutes (deuterium); 1 minute (tungsten
halogen) |
| Bulb life: |
~1500 hours (deuterium); 1500 hours
(tungsten halogen) |
~1500 hours (deuterium); 1500 hours
(tungsten halogen) |
| Ignition delay: |
<2.0 seconds (delay for cold start-up may
be longer) |
<2.0 seconds (delay for cold start-up may
be longer) |
| Connector: |
SMA 905 |
SMA 905 |
