Laser-Export脉冲激光器,多波长脉冲激光器,DPSS激光器

Laser-Export脉冲激光器,多波长脉冲激光器,DPSS激光器



俄罗斯Laser-export公司是生产世界一流的生产DPSS激光器的公司,公司主要提供脉冲激光器(紫外,绿光,红外及多波长)和DPSS激光器,用于各种不同的领域。



TUNABLE LASERS

Gain-switched

TiSon GSB New 710-890 nm up to 1 kHz, > 200 uJ and < 10 ns at 800 nm, automatic, PC controlled wavelength tuning

'TECHNOLOGY'-series lasers

Q-switched TECH-263 263 nm Basic 10 uJ@1 kHz or 25 uJ@1 kHz, 4 ns

Beam quality - TEM00, M2 < 1.2
Long term stability < 2% / 8 hrs
Range of pulse repetition rate:
0 - 4 kHz (for Basic andAdvanced)
0 - 1 kHz (for Specific andExpress)
Operating voltage - 24 V +/- 10%

Advanced 50 uJ@1 kHz, < 3 ns
TECH-351 351 nm Basic 50 uJ@1 kHz or 125 uJ@1 kHz, 5 ns
Advanced 200 uJ@1 kHz, < 5 ns
TECH-527 527 nm Basic 250 uJ@1 kHz, 5 ns
Advanced 500 uJ@4 kHz, 5 ns
Express 500 uJ@1 kHz, < 3 ns
Specific 1000 uJ@1 kHz, > 7 ns
TECH-1053 1053 nm Basic 500 uJ@1 kHz, 6 ns
Advanced 1000 uJ@4 kHz, 6 ns
Express 1000 uJ@1 kHz, < 4 ns
Specific 2000 uJ@1 kHz, > 10 ns

MULTI-WAVELENGTH LASERS

Q-switched TECH-263 Basic - 3 wavelength laser > 10 uJ at 263 nm, > 100 uJ at 527 nm, > 100 uJ at 1053 nm
TECH -351 Basic - 3 wavelength laser > 120 uJ at 351 nm, > 100 uJ at 527 nm, > 150 uJ at 1053 nm
TECH -527 Basic - 2 wavelength laser > 200 uJ at 527 nm, > 200 uJ at 1053 nm

ULTRAVIOLET LASERS

Q-switched DTL-375QT 355 nm 20 uJ at 1 kHz

Pulse width < 6 ns at 1 kHz.
Range of pulse repetition rate:
external - from single pulse to 30 kHz
through RS-232 - 0.01 - 30 kHz
internal without PC - 1 kHz.

GARNET 20 uJ at 200 - 2000 Hz, external triggering. Industrial model for OEM.

GREEN LASERS

Q-switched DTL-314QT 532 nm 25 uJ at 1 kHz Pulse width < 8 ns at 1 kHz.
Range of pulse Repetition Rate:
external - from single pulse to 30kHz
through RS-232 - 0.01 - 30kHz
internal without PC - 1 kHz.
Single-Frequency CW SLM-417 532 nm 20 and 50 mW, manual power adjustment, CDRH-compliant Single longitudinal mode
Line Width 0.00001 nm
Low noise (<0.1% RMS)
Coherence length >50m
LCM-S-111 10, 20 and 50 mW, 4.5 - 6 V DC / 4 A. Laser module for OEM
LCM-S-111-R (for Raman) 10 and 20 mW, 4.5 - 6 V DC / 4 A. High tolerance to back reflections. Laser module for OEM.
Continuous Wave DTL-413 527 nm 200, 350, 500, 1000 and 1500 mW. Noise level <1% RMS, RS-232 control
LCM-T-111 532 nm 1, 10 and 20 mW, 3.3 - 3.5 V DC / +/- 1.4 A. Laser module for OEM.
LCM-T-111-AP 10 and 20 mW, 5 V DC / +/- 1.4 A, power adjustment, TTL modulation. Laser module for OEM.
LCS-T-11 3 mW, AC Power Supply, CDRH-compliant
INFRARED LASERS
Q-switched DTL-324QT 1064 nm 100 uJ at 1 kHz Pulse width < 10 ns at 1 kHz.
Range of pulse Repetition Rate:
external - from single pulse to 30kHz
through RS-232 - 0.01 - 30kHz
internal without PC - 1 kHz.
Single-Frequency CW LCM-S-112 1064 nm 100 mW, 4.5 - 6 V DC / uJ 4A. Laser module for OEM. Single longitudinal mode
Line Width 0.00001 nm
Low noise (<0.1% RMS)
Coherence length >50m
Continuous Wave DTL-423 1053 nm 300, 1000, 2000 and 2500 mW

Noise level <0.5% RMS

RS-232 control
DTL-322 1064 nm 300, 1000 and 2000 mW
LCM-T-112 10, 100 and 200 mW, 3.3 - 3.5 V DC / +/- 1.4 A. Laser module for OEM.
LCS-T-12 50 mW, AC Power Supply, CDRH-compliant



TECH系列激光器资料下载

>
